This riflescope has been designed to give shooters (both tactical and sharpshooters) what they were craving for. It is perfect for fast, precise shooting to targets located in different, unknown distances. Specially designed reticles LRD-1P, LRD-1T, DLR-1 are placed in the first focal plane (FFP). They are Miliradiant-based (MIL), convenient to convert into metric units (1 Mil = 10 cm at 100m) and correspond with the riflescope’s clicks - 1 click is 0.1 MIL (10mm).
Carefully selected ED glass significantly reduces chromatic aberration throughout the entire magnification range. High-end, multi-layer, anti-reflective coatings ensure unsurpassed contrast and well-defined, sharp image of the target.
Sleek and robust 34mm diameter tube provides vertical adjustment up to 300cm and allows you to mount the riflescope on a weapon with a calliber of up to .50 BMG.
Comfortable lockable open turrets for both hands-on or gloved usage with the ZeroLock mechanism which allows to set limit for elevation - usually after zeroing the riflescope at preferred shooting distance. The lock allows to make corrections of elevation without taking your eyes off the target!
All these brilliant features come to you in a compact form of a riflescope with the length of just 365mm and a weight of 1014g.
Specification
| Minimum magnification: |
4.5x |
| Maximum magnification: |
30x |
| Lens diameter: |
56 mm |
| Reticle name: |
LRD-1P |
| Grid position: |
first focal plane (FFP) |
| Mesh Backlight: |
central cross |
| Distance from the eye: |
81 - 97 mm |
| Exit pupil: |
12.44 - 1.87 mm |
| Linear field of view at 100 m: |
8.3 - 1.2 m |
| Angular field of view: |
4.72 - 0.71 ° |
| Turret type: |
Open |
| Vertical adjustment range: |
30 MRAD |
| Horizontal adjustment range: |
15 MRAD |
| Single click adjustment: |
0.1 MRAD |
| One turret rotation: |
10 MRAD |
| Parallax adjustment: |
23m - ∞ |
| Diopter correction: |
-2D/+3D |
| ZeroStop: |
Yes |
| Length: |
365 mm |
| Tube diameter: |
34 mm |
| Lens outer diameter: |
65 mm |
| Eyepiece outer diameter: |
44 mm |
| Libra: |
1004 g |
| Sun visor thread: |
M62x0.6mm |
| Water resistance: |
0.3 kg/cm2 |
| Nitrogen filling: |
Yes |
| Operating temperature: |
-20 / 71 °C |
| Shock resistance: |
6500 J |
| Battery type: |
CR2032 |
| Warranty period: |
120 months |
